V-TUF Manual Motor Starter with Push Button

V-TUF Manual Motor Starter with Push Button (I10.914 / I10.1218 / I10.2025) is a manual motor starter with adjustable thermal overload protection and integral push button, available in three current ranges: 9–14A, 12–18A, and 20–25A with a 25A limit. The most popular manual starter for 415v commercial and industrial electric motor protection on pressure washers and pumps.

For: 415v commercial and industrial electric motor protection on pressure washers, pump sets, and powered equipment requiring manual start/stop with overload protection.

Key specifications:

• Current ranges: 9–14A (I10.914), 12–18A (I10.1218), 20–25A (I10.2025)
• Max limit: 25 amp
• Type: Manual motor starter with thermal overload and push button
• Application: 415v motor protection

What's included:

• 1x manual motor starter in selected amp range

Important: Select the amp range to match your motor's full load current. Use with enclosure kit I10.500K for outdoor or wet environments.

Support: See the Electrical Spare Parts page for self-service help, or call our Lincoln service team on 01522 787978.

Genuine V-TUF part, supplied from our Lincoln warehouse.
