GEARBOX - V-TUF SUPER SERIES XHDG500SS 1" HOLLOW SHAFT FOR UP TO 31 HP ENGINES & 24MM PUMP SHAFT 1:2.3 - XHDG500SS

V-TUF XHDG500SS Super Series Gearbox 1" Hollow Shaft (XHDG500SS) is the V-TUF SUPER SERIES reduction gearbox with 1" hollow shaft for engines up to 31HP and 24mm pump shaft output at a 1:2.3 ratio. Larger oil bath than standard gearboxes for reduced heat in continuous high-powered operation. Suits XHDM400SS, XHDM450SS, and XHDM500SS pumps.

For: Engine-driven industrial pressure washing systems using V-TUF XHDM SUPER SERIES pumps, high HP petrol and diesel engines up to 31HP.

Key specifications:

• Shaft input: 1" hollow (for engine crankshaft)
• Shaft output: 24mm (for XHDM SS pumps)
• Ratio: 1:2.3
• Max engine HP: 31HP
• Compatible pumps: XHDM400SS, XHDM450SS, XHDM500SS

What's included:

• 1x XHDG500SS gearbox

Important: Fill with correct gearbox oil before first use. Do not exceed 31HP engine rating. Confirm 1" hollow shaft matches your engine crankshaft before ordering.

Support: See the XHDM Spare Parts page for self-service help, or call our Lincoln service team on 01522 787978.

Genuine V-TUF part, supplied from our Lincoln warehouse.
