PUMP - V-TUF SUPER SERIES XHDM350SS 15L @ 150BAR, 1450RPM 24mm MALE SHAFT - XHDM350SS
PUMP - V-TUF SUPER SERIES XHDM350SS 15L @ 150BAR, 1450RPM 24mm MALE SHAFT - XHDM350SS
Description
SUPER SERIES XHDM350SS Solid Shaft Pump - 15L/MIN @ 160BAR, 1450RPM, 24mm Solid Shaft.
1450 RPM ideal to be driven by: MH.243 240 volt motor or by the XHDG200 gearbox to connect to a engine. 6.5 HP required to run at full pressure: Super robust transmission system, 3-piston alternating volumetric pump for use on heavy use cleaning units and industrial systems to reduce downtime and running costs. SUPER Robustly made with a perfect balance of weight to ensure minimum fatigue on motor and gearbox mountings. NICKEL PLATED SOLID BRASS PUMP HEAD - Greater heat & weather resistance Pump body and cover in die-cast aluminium alloy with cataphoretic coating. Cathaphoresis painting is a surface treatment intended to give metal elements and other alloys a considerable resistance to chemical and environmental corrosion. Rear cover with oil drain outlet and oil sight glass. Cap with dipstick for oil level on body pump. Pistons driven by super series crank-connecting rod mechanism. Pump shaft in pressed high-strength steel. SEAL KIT VTPKIT135 VALVE KIT VTPKIT2 OIL: PL500
